160CPS - Getting It Right The First Time

Preset shaper cutters and Power Skiving cutters on the 160CPS Cutter Presetting Device to get it right the first time.


Measurable outside diameter 340 mm
Cutter holder plus Cutter weight, max. 50 kg

Reduced Scrap

Achieve the desired tolerances in size-over-balls or tooth thickness already on the first workpiece, and reduce scrap and cost.

Additional Functions

Optionally, test run-out, inspect the cutter outside diameter, and check tool wear.

Corrections in No Time

Directly transfer measured data to the shaping or Power Skiving machine via USB, RFID or network. The Closed Loop for Power Skiving is ideally suited for automated production.

Record Productivity

Manage cutters and cutter holders, record tool life, and monitor cutter condition and sharpenings.

Data Matrix Reader

Automatically read cutter data into the tooling database to monitor cutters and recall cutter data at any given time.
