ZS Series - The Universal Shaving Machines with Optional Chamfering/Deburring

Several machine executions in different combinations are available to meet all customer requirements in fine finishing of non-hardened spur and helical gears: ZS150 (universal shaving), ZS150T (plunge shaving), ZSE (chamfer rolling option).



Workpiece diameter, max.
200 mm
Module plunge shaving, max.
3.5 mm
Module parallel or diagonal shaving, max.
5 mm
Workpiece length, max.
400 mm

Lead Modifications Made Easy

The extra rigid machine allows for easy lead modifications enabled by its moving tool cradle design while the workpiece axis remains in a fixed position.

Good Workpiece Quality at Minimal Machining and Tool Cost

ZS Shaving Machines are highly productive gear shaving solutions. No matter which solution you choose, it will render excellent results at minimum cost.

Optional Integrated Chamfer Rolling Process in Parallel to Shaving

Gleason Chamfer Rolling Tools combine constant and repeatable chamfering results with excellent tool life for minimal cost-per-piece.

Master of Mass Production

With several automation options like pallet ring conveyor or loading slides, the ZS Series will easily integrate into new or existing mass production environments.
