1000T to 2500T - Fast, Flexible Roll Testing of Large Gears, all Types
Gleason 6-axis fully CNC Universal Gear Testers are in a class by themselves. They are the only products that can perform the full range of pattern checking and single flank testing on bevel gears with a wide range of shaft angles for diameters up to 2,500 mm, as well as parallel-axis and off-angle cylindrical gears, with diameters as large as 1,000 mm.
| Workpiece diameter, max. | 2,500 mm |
| Range of shaft angle | 30 - 180° |
Fully CNC-Controlled
6-axis fully CNC-controlled Universal Gear Tester.
Up to 2500 mm
Roll testing and single flank testing for bevel and cylindrical gears up to 2500 mm outside diameter.
User-Friendly Control
Siemens 840D or Fanuc 31i controller.
Easy-to-Use
Ease of set-up and highest flexibility.
