outside blade No. 1 and inside blade No. 14. Enter the master blade num-
bers in the pop-up tab shown in Figure 9. All other blades (except No. 11)
need to be adjusted to a larger radius, which is what torquing the RT ad-
justment screw accomplishes.

Figure 8: Measurement results

Figure 9: Selection of master blade
