shaft was manufactured with an English standard hob and the sprocket is
manufactured with a Metric standard hob, as long as both members use the
appropriate profile shift which will assure that the reference diameters of shaft
and internal spline are identical. Also, a simple method for determining the
pressure angle of an existing spline has been presented. The result was com-
pared to the ANSI and ISO table of recommended spline pressure angles
which allowed a mature choice of the closest value.

The final section of the article aids in the selection of a hob cutter for the shaft
and a shaper cutter for the internal spline. For the correct setup of the manu-
facturing machine the calculation of the center distances between work and
tool was presented.

14.7 Literature

[1] AGMA 945-A18 “Splines - Design and Application”, published by the Ameri-
can Gear Manufacturers Association, November 2018

[2] ANSI B92.1 “Standard, Involute Splines and Inspection”, published by
Society of Automotive Engineers, 1996

[3] ISO 4156-2005 “Standard, Straight cylindrical involute splines - Metric mod-
ule, side fit”, published by International Organization for
Standardization, 2005

[4] ISO 14 “Standard, Straight-sided splines for cylindrical shafts with
internal centering - Dimensions, tolerances and verification”,
published by International Organization for Standardization,
1982

[5] DIN 5480 “Standard, Splined connections with involute splines based
on reference diameters”, published by DIN Deutsches Insti-
tut für Normung e.V., Berlin, 2006

[6] JIS B 1603-1995 “Standard, Straight Cylindrical Involute Splines - Side Fit -
Generalities, Dimensions and Inspection”, published by Jap-
anese Standards Association, 1995

[7] JIS D 2001-1959 “Standard, Involute Spline For Automobiles”, published by
Japanese Standards Association, 1959
